Huawei SUN2000-8KTL-M1 – General Specifications
Betriebstemperaturbereich: -25 ~ +60 °C Relative Betriebsfeuchtigkeit: 0 % RH~100 % RH Betriebshöhe: 0 – 4.000 m (Derating > 2.000 m) Kühlung: Konvektionskühlung Anzeige: LED – Anzeige Kommunikation: RS485, WLAN, Ethernet über Smart Dongle-WLAN-FE; 4G/3G/2G über Smart Dongle 4G (optional) Gewicht (inkl. Befestigungswinkel): 17 Kg Abmessungen (inkl. Befestigungswinkel): 525 x 470 x 146.5 mm Schutzart: IP65 Energieverbrauch nachts: < 5,5 W (<10 W, wenn die PID-Wiederherstellungsfunktion aktiviert ist)
Huawei SUN2000-8KTL-M1 – Input (DC)
Recommended maximum PV power1: 12,000 Wp Max. Input voltage2: 1,100 V Operating voltage range3 : 140 V ~ 980 V Starting voltage: 200 V Rated input voltage: 600 V Max. input current per MPPT: 11 A Max. input current per MPPT: 1,100 V Input current per MPPT: 11 A Max. short-circuit current: 15 A Short circuit current: 15 A Number of MPP trackers: 2 Max. number of inputs per MPPT: 140 V ~ 80 V Number of inputs per MPPT: 1
Huawei SUN2000-8KTL-M1 – Input (DC Battery)
Compatible battery: HUAWEI Smart String ESS 5kWh – 30kWh Operating voltage range: 600 V ~ 980 V Maximum operating current: 16 A Maximum charging power: 10,000 W Maximum discharging power: 8,800 W
Huawei SUN2000-8KTL-M1 – Output (On Grid)
Mains connection: three-phase Rated power: 8,000 W Maximum apparent power: 8,800 VA Rated output voltage: 220 Vac / 380 Vac, 230 Vac / 400 Vac, 3W / N+PE AC mains frequency: 50 Hz / 60 Hz Maximum output current: 13.5 A Adjustable power factor: 0.8 cap. … 0.8 ind. Total harmonic distortion (THD): ≤ 3%
Huawei SUN2000-8KTL-M1 – Protection and function
DC load break switch: Yes Islanding detection: Yes DC reverse polarity protection: Yes Insulation monitoring: Yes DC overvoltage protection: Yes, compatible with protection type TYPE II according to EN / IEC 61643-11 AC overvoltage protection: Yes, compatible with protection type TYPE II according to EN / IEC 61643-11 Fault current monitoring: Yes AC overcurrent protection: Yes AC short-circuit protection: Yes Arc detection: Yes Inputs for ripple control receivers: Yes Integrated PID recovery: Yes Battery charging from mains possible: Yes
Huawei SUN2000-8KTL-M1 – Module Optimizer
DC MBUS compatible optimizer: SUN2000-450W-P
Huawei SUN2000-8KTL-M1 – Standards Compliance (others available upon request)
Safety standards: EN/IEC 62109-1, EN/IEC 62109-2, IEC 62116 Mains connection standards: G98, G99, EN 50438, CEI 0-21, VDE-AR-N-4105, AS 4777, C10/11, ABNT, UTE C15-712, RD 1699, TOR D4, NRS 097-2-1, IEC61727, IEC62116, DEWA
Huawei SUN2000-8KTL-M1 – included in delivery
PV Connector Battery Connector AC Connector Signal Cable Connector Bracket WLAN-FE-Dongle
